Product Specification
50kW high power & high voltage generator,large heat capacity of X-ray tube and high quality wireless flat panel detector, meet the needs of full-body photography.
21.5 inch big size touch screen, ultra-narrow border design and wide field of vision enhance display effect.
Equipped with dynamic lithium battery, which has advantages of greatly shortened charging time, more exposure and increased battery service life.
Main Components |
Technical Specifications |
|
Flat Panel Detector |
X-ray Sensitive Area |
14x 17/17x17inch |
Generator |
Standard Power |
50kW/45kW |
kVp Range |
40-150kVp |
|
mA Range |
10~ 630mA . |
|
mAs Range |
0.1~360mAs |
|
X-ray Tube |
Anode Heat Content |
150/300kHU |
Physical Specification
|
Weight |
380kg |
Height |
184cm |
|
Width |
55cm |
|
Column Rotation Range |
±315° |
|
Tube Tilting Angle |
±180° |
|
Tube Vertical Rotation Angle |
-30°~ +90° |
|
Telescopic Arm Length Range |
730~ 1250mm |
|
SID |
610~ 1830mm |
